Features & Specifications
Waterproof,Heat resistance,pressure resistance,cold resistance.
Working voltage: 3.5-12VDC.
Frequency: F=23 * Q (L / Min) error: ± 2%
F=onstant * units of flow (L / min) * time (seconds).Flow range:0.3-10L/min
Maximum current:1.5 mA(DC 5V)
Operating Temp:≤80℃,Operating humidity:35%～90%RH
Pressure range: 0.1-0.8MPa
Storage Temperature:-25～+80℃
Storage humidity:25%～95%RH
Output Waveform:Square Wave,output pulse singal.
ROHS Compliant.
Cable length:15cm.
